Used Digger - Official Technical Overview & Datasheet

EXECUTIVE SUMMARY The HD-330R Certified Used Digger is a pre-owned, factory-reconditioned medium-duty hydraulic excavator engineered for contractors and mine service operators who demand enterprise-grade reliability at optimized capital expenditure. Rigorously inspected under ISO 24430 guidelines, this unit targets the secondary construction market, artisanal mining operations, and large-scale agricultural trenching where new-equipment ROI is protracted. Every HD-330R undergoes a 237-point remanufacturing process including NDT chassis crack detection, powertrain dynamometer validation, and hydraulic contamination flushing. With a residual service life of 6,500+ operating hours and immediate parts availability, the machine delivers Tier 4 Final emissions compliance while retaining aggressive digging forces up to 145 kN. The value proposition: new-machine capability, used-machine economics.
