40HP Remote Controlled Land Reclamation Robot for Firebreak Clearing Stump Removal Wasteland Widening

Name: 40HP Remote Controlled Land Reclamation Robot for Firebreak Clearing Stump Removal Wasteland Widening
Brand: GLOBALMACHEX
Availability: InStock
Rating: 5 (1 reviews)

Product Introduction: 40HP Remote Controlled Land Reclamation Robot for Firebreak Clearing, Stump Removal & Wasteland Widening

This model is the 40-type full hydraulic remote-controlled reclamation machine powered by a Yanmar diesel engine, model HYZH-40. It is a multi-functional all-terrain engineering robot specially designed for forest firebreak construction, stump removal, wasteland renovation, municipal green maintenance and dyke hazard cleaning.

$28000.00 - 35000.00

Send Message Contact Supplier

Qingdao Huaying Intelligent Equipment Co., Ltd.

View Supplier

Year Established Established in 2024

Employees Less than 50 People

Factory Area 1,000-5,000 m²

Annual Revenue US$1 Million - US$5 Million

Main Markets Europe / Latin America

Details

Trade Information

1. Core Power & Hydraulic Performance

Fitted with a direct-injection Yanmar diesel engine with a rated power of 28.2kW (40HP), it delivers a peak torque of 107.1Nm. The machine adopts a combined piston and gear hydraulic pump system with a working pressure of 250bar and a hydraulic flow of 84L/min for the reclamation attachment. It features oil-air hybrid cooling plus a self-developed bidirectional fan cooling system; the reversible fan controlled by remote or timer can blow dust off the cooler, guaranteeing stable heat dissipation even under long heavy-load operations. The hydraulic system holds 26L hydraulic oil in the tank and a total system volume of 40L. High-torque drive motors and hydrostatic precision transmission enable stepless speed regulation: working speed ranges 0–4km/h forward and reverse, while transit speed hits 0–10.2km/h.

2. Outstanding All-Terrain Passability

Equipped with high-tooth rubber tracks twice thicker than standard tracks on the market, the machine boasts strong ground grip and terrain adaptability:

Cross vertical obstacles up to 500mm, wade through 500mm-deep water;
Standard working slope capacity of 55°, and the hydraulic system tolerates a static tilt angle up to 80°;
Operate safely on any terrain with a 60° arbitrary operating inclination after engine optimization;
Ground clearance of 170mm, departure angle of 30°, straight-line deviation controlled within 0.3%;
The attachment automatically fits terrain undulations within ±10°, keeping consistent cutting depth on uneven ground.

Other mobility highlights include skid steer with zero-radius in-place turning, a 500mm forearm lifting range (-200mm to 500mm), and a maximum traction force of 25KN. Its overall dimension is 3230×1450×1420mm with a self-weight of 1840kg.

3. Professional Cutting & Reclamation Attachment

The standard working width reaches 1200mm, fitted with 27 tungsten steel cutting tools rotating bidirectionally at 2500rpm with stepless 0–100% adjustable rotation speed. It crushes stumps with a maximum diameter of 100mm and can backfill topsoil up to 20mm deep during firebreak construction. The front cover of the cutter head can be opened and closed remotely for easy debris clearing. Imported quick connectors support full attachment replacement within 10 minutes, and side shift of the cutter head is available as an optional upgrade for flexible edge trimming.

4. Full-Function 2.4G Remote Control System

The remote control signal covers over 150 meters. It supports full remote operation: engine start/stop, throttle adjustment, LED headlights, horn, cutter head movement, and front cover switch. Proportional joysticks allow forward/reverse travel mode switching without U-turns for higher efficiency. Two built-in rechargeable lithium batteries power the remote controller with self-charging support.

MOQ

1 Sets

Lead Time

25days

Description

1. Core Power & Hydraulic Performance

2. Outstanding All-Terrain Passability

Equipped with high-tooth rubber tracks twice thicker than standard tracks on the market, the machine boasts strong ground grip and terrain adaptability:

Cross vertical obstacles up to 500mm, wade through 500mm-deep water;
Standard working slope capacity of 55°, and the hydraulic system tolerates a static tilt angle up to 80°;
Operate safely on any terrain with a 60° arbitrary operating inclination after engine optimization;
Ground clearance of 170mm, departure angle of 30°, straight-line deviation controlled within 0.3%;
The attachment automatically fits terrain undulations within ±10°, keeping consistent cutting depth on uneven ground.
