Fully hydraulic remote-controlled slope lawn mower

Name: Fully hydraulic remote-controlled slope lawn mower
Brand: GLOBALMACHEX
SKU: HYZH-40PRO
Availability: InStock
Rating: 5 (1 reviews)

This fully hydraulic remote-controlled mower is built for vegetation maintenance on steep slopes, river embankments, highways and photovoltaic power stations, working stably on slopes up to 55°. It is equipped with a Yanmar diesel engine and B&P brand pumps. Fitted with high-grip tracks, a 2.4G wireless remote control and a 1350mm adjustable cutting width, it allows quick attachment changes for efficient multi-scenario operations. Multiple safety features including tilt auto-shutdown, signal loss protection and emergency stop are provided.

$27700.00 - 32700.00

Send Message Contact Supplier

Qingdao Huaying Intelligent Equipment Co., Ltd.

View Supplier

Year Established Established in 2024

Employees Less than 50 People

Factory Area 1,000-5,000 m²

Annual Revenue US$1 Million - US$5 Million

Main Markets Europe / Latin America

Details

Specifications

Trade Information

We are an original manufacturer providing global OEM & ODM services. Customization of machine appearance, body colors and brand logos is available to fit your market demands. A wide range of attachments are optional, including land clearing heads, snow blowers and ditchers. Custom attachments can also be developed upon your special requirements.

Yanmar 3-cylinder 4-stroke water-cooled direct injection engine Model 3TN88
28.2kW diesel engine with a max horsepower of around 40 HP and maximum speed below 3200 rpm. It delivers nearly peak torque at only 1000 rpm.
Imported Italian B&P hydraulic system with electro-proportional servo control
The integrated hydraulic power unit is fully imported, consisting of 3 variable displacement pumps and 2 gear pumps. Adopting world-leading proportional control technology, it precisely regulates flow output to ensure balanced power distribution for all components.
The mowing deck oil pump system is equipped with a cut-off function to avoid engine stall caused by excessive load.
Dual hydraulic motor drive with two imported Poclain travel motors from Germany
The motors feature two-speed modes, automatic parking brake and remote parking brake. The low-speed range tops out at 4 km/h while high-speed reaches 8.6 km/h. Operators can freely switch between speeds via remote control for flexible operation in diverse working conditions. The low-speed range supports stepless speed regulation from 0 to maximum speed.
Optimized engine oil distribution plate design
The machine allows a maximum tilt angle of 55°; long-term stable operation is available at 30°, and short-term operation at 35°.
We independently upgraded the engine lubrication structure to enable operation on steep slopes, with a theoretical limit tilt angle up to 60°.
Self-developed reversible dual fan cooling system with regular & forced cleaning modes
Equipped with a miniature air compressor and reversible fan blades. The fan can blow forward or backward via remote control or timed program, cooling the engine and blowing away accumulated dust simultaneously.
High-lug rubber tracks for superior traction on steep slopes
Custom heavy-duty rubber tracks with lugs twice taller than standard market tracks, delivering outstanding grip and friction for all terrain conditions.
Cooling system
Custom integrated oil-water combined cooling system provides efficient heat dissipation under all permissible operating environments.

ENGINE

YANMAR 3-Cylinder, 4-cycle, inline, water-cooled diesel

Torque

100.7 Nm

Fuel

Diesel

Fuel tank

28 litres

Gross output

27.5Kw (37.4Hp) @3000rpm

Transmission

Fine control hydrostatic

Water-cooled radiator

2-core heavy duty

Max gradient

55° in all directions (after engine optimization)

HYDRAULICS Pump

Piston pump + gear pump (B&P)

Travelling motor

High torque motor (B&P)

Auxiliary flow

79.8L/min (Max. 280bar)

Oil tank capacity

23 litres (40 liters held in system)

Arm lifting capacity

750Kg

REMOTE CONTROL Working range

>150m

Frequency

2.4G

PERFORMANCE Gradient

Working on slope up to 55° in all direction (alarm at 50°, automatic shut-off at 55°)

Potentiometer speed control(0 to 100%)

1st gear, forward/backward 0-4 Km/h ；2nd gear, forward/backward 0-9 Km/h

MOQ

1 Pieces

Trade Terms

FOB, CIF, DDP, DAP

Description

Yanmar 3-cylinder 4-stroke water-cooled direct injection engine Model 3TN88
28.2kW diesel engine with a max horsepower of around 40 HP and maximum speed below 3200 rpm. It delivers nearly peak torque at only 1000 rpm.
Imported Italian B&P hydraulic system with electro-proportional servo control
The integrated hydraulic power unit is fully imported, consisting of 3 variable displacement pumps and 2 gear pumps. Adopting world-leading proportional control technology, it precisely regulates flow output to ensure balanced power distribution for all components.
The mowing deck oil pump system is equipped with a cut-off function to avoid engine stall caused by excessive load.
Dual hydraulic motor drive with two imported Poclain travel motors from Germany
The motors feature two-speed modes, automatic parking brake and remote parking brake. The low-speed range tops out at 4 km/h while high-speed reaches 8.6 km/h. Operators can freely switch between speeds via remote control for flexible operation in diverse working conditions. The low-speed range supports stepless speed regulation from 0 to maximum speed.
Optimized engine oil distribution plate design
The machine allows a maximum tilt angle of 55°; long-term stable operation is available at 30°, and short-term operation at 35°.
We independently upgraded the engine lubrication structure to enable operation on steep slopes, with a theoretical limit tilt angle up to 60°.
Self-developed reversible dual fan cooling system with regular & forced cleaning modes
Equipped with a miniature air compressor and reversible fan blades. The fan can blow forward or backward via remote control or timed program, cooling the engine and blowing away accumulated dust simultaneously.
High-lug rubber tracks for superior traction on steep slopes
Custom heavy-duty rubber tracks with lugs twice taller than standard market tracks, delivering outstanding grip and friction for all terrain conditions.
Cooling system
Custom integrated oil-water combined cooling system provides efficient heat dissipation under all permissible operating environments.
