1. Changchai Power & High-Performance Triple Pump Hydraulic System
Equipped with Changchai 390 water-cooled diesel engine with 20kW high power output, theoretical fuel consumption only 1.3-1.6L/h, widely available spare parts at home and abroad. High-end triple pump confluence hydraulic system with dual pilot joysticks realizes smooth synchronous compound movements and greatly improves work efficiency. Integral forged hydraulic cylinders fitted with imported Japan NOK oil seals, 3-layer steel wire explosion-proof high-pressure hoses eliminate oil leakage during long continuous work, standard independent foot pedal control valve for rock breaker.
2. Wide Chassis Heavy-Duty Rubber Track Travel Gear
Fixed wide chassis 1400mm, track shoe width 230mm, track ground contact length 1350mm, large ground contact area prevents sinking on muddy and soft ground. Powerful 35° gradability ensures stable reclamation work on mountain and slope land. Wide front dozer blade stabilizes machine during digging and completes backfilling & site leveling at the same time. Travel speed 3km/h for flexible short-distance transport. Integrally stamped reinforced chassis, robot fully welded boom & stick with thick built-in reinforcing ribs for excellent anti-impact & anti-deformation performance.
3. Large Working Range & Fast Attachment Replacement
Standard 430mm wide digging bucket with capacity 0.05m³, boom length 1800mm, arm length 1000mm. Max digging height 3230mm, max dumping height 2350mm, max digging depth 2300mm, earthmoving efficiency far exceeds 1~1.8 ton mini excavators. Full 360° zero-dead-angle swing with zero tail counterweight, no scratch on walls and saplings when rotating in residential areas, orchards and narrow construction sites. Quick coupler enables fast replacement of hydraulic breaker, auger drill, log grab and rake for multi-work of digging, rock breaking, drilling and timber grabbing.
4. Open Operation Design With Sunshade Canopy
Standard detachable metal sunshade roof blocks sunlight and rain in summer. Open cab delivers excellent ventilation and heat dissipation, suitable for long-term open-air construction. Shock-absorbing suspension seat relieves fatigue during long-hour operation. Fully transparent operating vision without cab obstruction for more intuitive observation in narrow spaces. Overall dimension 310014002250mm, transportable by medium flat trailer with low transportation cost.
5. Application Scenarios & Export Supply Advantages
Main applications: municipal pipeline excavation, mountain land landscaping reclamation, orchard deep fertilizing ditching, large villa courtyard renovation, rural small infrastructure and construction earth breaking. CE & ISO certified to meet agricultural & construction machinery import standards of most countries worldwide. Lake blue/yellow/red body color optional, extended boom and full set of attachments customizable. Machine packed in reinforced solid wooden frame / steel frame for sea shipment, sufficient factory ready stock, long-term stable supply for overseas contractors, landscape rental companies and farm traders.
